50hz Industrial Robotic Automatic Screwdriver Machine XYZ Axis

50hz Industrial Robotic Automatic Screwdriver Machine XYZ Axis

Features :auto feed screwdriver

1 , Auto-intelligent detection for screw loose , screw missing ,screw unstable .K576
2 , Automatic feeding and lock screws , Any screw hole point and location data can
be stored in the system at any time .auto feed screwdriver
3 , Excellent commonality and easy replace Screw M 2.0—M 5.0
4 , Using X , Y , Z axis operation movement system control .

Technical Parameters :

Machine size : 500 * 620 * 630 ( L * W * H )

Screwing range : 200 * 390 * 70mm ( X * Y * Z )

Drive mode : 4-axis precision stepper drive

Positioning accuracy : ± 0.02mm

Control system : PLC + touch screen control system

Screw delivery method : draw style

Screw feeding quantity :1 -2 group

Screw delivery method : Teach-

Efficiency : Min <1.5s

Program storage capacity : 100 groups , 100 points / group

Communication port : USB

Power supply : 220VAC , 50HZ

Air source : 0.4Mpa

Total Weight : 60kg

Advantages

1. One machine can reduce 30% human power , you can reduce two screwing workers .
2. can be set through the touch screen coordinate value and the product of the screw , can be applied to a variety of common products . If the screw on the product specification is basically the same , you only need to replace the fixtures they can use the product , the entire process is completed in less than 10 minutes .
3. monitor the entire quality of the equipment lock screw , in the event of bad touch will alarm and display the type of defective products .
4. Automatic clutch after the screwdriver reach the torque , ensure that each lock screws Vice torque control ± 10%.
5. main parts are die steel production , abrasion resistant plastic deformation , equipment, body spray paint , oil and scratch resistant .
6. humane touch -screen operation and ease of operation , external technical parameters and manual test function can be directly adjusted by technicians.
7. The machine are small, save production line pace , easy moving .

Package : plywood case ,
